Features

Table

·      1.25’’ thick textured vinyl-covered non-resonant MDF
       chassis

·      16’’ x 11’’footprint

·      19” x 14” x 6” overall size

·      Aluminium Platter

·      Platter rotates on an oil bath bearing and fitted to
       shaft with a #2 Jacob’s Taper for a concentric rigidly
       mounted coupling

·      The bearing has a PEEK thrust disc and machined
       graphite impregnated brass bushings using a
       Thompson Engineering 60 Rockwell case hardened
       shaft

​Tonearm:

·      New 9” vertical Yoke type tonearm with lateral
       turntable type bearing

·      Pivot to spindle: 223mm

·      Effective length: 240.7mm

·      Overhang: 17.7mm

·      Offset angle: 22.85 degrees

·      Average RMS distortion: .36%

·      VTA adjustable arm mount.

·      Damped stainless steel armtube.

·      Very pure copper wire, twisted with special insulating
       jacket

·      The armbase is upgradeable to a standard JMW 9 arm

​Specifications

Type: Belt drive (manual turntable)

Motor: 24 V synchronous AC motor

Turntable platter: Aluminum

Diameter: 11.81” (30.0 cm)

Turntable speeds: 33.3 RPM and 45 RPM

Cartridge: Audio Technica AT-VM95E

Output: 5 mV @ 1 KHz

Tracking force: 1.5 g (recommended)

Input load: 47 kOhm

Dimensions (WDH): 18.5” x 13.5” x 4.3”

Weight: 12.9 lb (5.9 kg)
